Pure Polyester TP-601 (97:3) – HAA Powder Coating Resin

Pure Polyester TP-601 (97:3) is a saturated, carboxylated polyester resin developed for Primid/HAA-cured powder coating formulations. It is designed for slow-curing systems requiring excellent outdoor durability and weather resistance.

TP-601 (97:3) can be dry blended with a suitable HAA curing component such as YC9550 and is suitable for producing super-weather-resistant powder coatings.

Key Features

Product: TP-601 (97:3)

Chemical type: Saturated carboxylated polyester resin

Technical grade

Delivery form: Flakes

Designed for HAA/Primid curing systems

Slow-curing formulation

Excellent weather resistance

Suitable for exterior powder coatings

Suitable for white and decorative powder-coating formulations

Principal Properties

Property Specification Unit

Acid Value 18–22 mg KOH/g

Viscosity, Brookfield at 200°C 3500–5500 mPa·s

Colour, ISO 7724 Max. 10 b*

Typical Applications

Exterior powder coatings

Super-weather-resistant powder coatings

HAA/Primid-cured coatings

Industrial metal coatings

Architectural and decorative coatings

Protective coating formulations

Storage & Shelf Life

Store the resin indoors in the original, unopened and undamaged packaging in a dry location at temperatures below 30°C. Avoid direct sunlight and excessive heat.

Shelf life: 1 year ex works under recommended storage conditions. Based on experience, the resin may remain stable for longer when properly stored, subject to appropriate quality inspection.

Processing Information

Typical extrusion conditions:

Equipment: Twin-screw extruder

Setting temperature: approximately 115°C

Speed: approximately 200 rpm

Typical application:

Corona spray gun

Voltage: 60 kV

Coating thickness: approximately 50 microns

Suitable for chromate-pretreated aluminium panels

Typical curing cycles:

180°C for approximately 10 minutes, or

200°C for approximately 10 minutes

Actual processing and curing conditions should be validated for the complete powder-coating formulation and application system.

Safety & Documentation

Material safety information and test-method documentation can be provided on request. Users should consult the manufacturer's current SDS/TDS and follow appropriate chemical-handling procedures.

Delivery Form: Flakes

Grade: Technical Grade

Suitable for: Powder coating manufacturers, resin formulators, industrial coating producers and chemical distributors.

Bulk quantities and commercial enquiries welcome.
